System Time

The system time is displayed at the lower right corner of the screen in "hh:mm

(hour:minute)" format. When printing or storing a waveform, the file output will

contain this time information.

Press Utility  System  System Time  System Time to turn on the setting

interface as follows.

Figure 13-2 System Time Setting Interface

In the figure, the item in green (such as 2013) is the item that can be modified

currently. Use to modify and press down to complete the input. The order of

time modifications is: year (2013) → month (04) → date (13) → hour (10) →

minute (20) → second (49). The setting range of each item conforms to the

convention:

 Year: 2011 to 2099

 Month: 01-12

 Date: 01-31 (28, 29 or 30)

 Hour: 00 to 23

 Minute: 00 to 59

 Second: 00 to 59

Press Apply to put the current setting into effect. The time at the lower right corner

of the screen will be updated.
