Chapter 16 Specifications RIGOL
DS2000E User’s Guide
16-3
Trigger
Trigger Level
Range
Internal
± 5 div from the center of the screen
EXT
± 4 V
Trigger Mode
Auto, Normal, Single
Holdoff Range
100 ns to 10 s
High Frequency
Rejection
[1]
75 kHz
Low Frequency
Rejection
[1]
75 kHz
Trigger
Sensitivity
1 div (below 10 mV or noise rejection enabled)
0.3 div (above 10 mV and noise rejection disabled)
Edge Trigger
Edge Type
Rising, Falling, Rising/Falling
Pulse Trigger
Pulse Condition
Positive Pulse Width (greater than, smaller than, within a
specific range)
Negative Pulse Width (greater than, smaller than, within a
specific range)
Pulse Width
2 ns to 4 s
Runt Trigger
Pulse Condition
None, >, <, <>
Pulse Polarity
Positive, Negative
Pulse Width
Range
2 ns to 4 s
Windows Trigger (Optional)
Windows Type
Rising, Falling, Rising/Falling
Trigger Position
Enter, Exit, Time
Windows Time
16 ns to 4 s
Nth Edge Trigger (Optional)
Edge Type
Rising, Falling
Idle Time
16 ns to 4 s
Number of Edges
1 to 65,535
Slope Trigger
Slope Condition
Positive Slope (greater than, smaller than, within a specific
range)
Negative Slope (greater than, smaller than, within a specific
