Rigol DS2102E [277/283] General specifications
![Rigol DS2202E [277/283] General specifications](/views2/1472934/page277/bg115.png)
Chapter 16 Specifications RIGOL
DS2000E User’s Guide
16-7
Persistence Time
Min, 50ms, 100ms, 200ms, 500ms, 1 s, 2 s, 5 s, 10 s, 20 s,
Infinite
Display Type
Dots, Vectors
Real-time Clock
Time and Date (adjustable for users)
I/O
Standard Ports
USB HOST (USB-GPIB supported), USB Device, LAN, Aux
Output (TrigOut/PassFail)
General Specifications
Probe Compensation Output
Output Voltage
[1]
About 3 V, peak-peak
Frequency
[1]
1 kHz
Power
Power Voltage
100 V to 240 V, 45 Hz to 440 Hz
Power
Maximum 50 W
Fuse
2 A, T Degree, 250 V
Environment
Temperature
Range
Operating: 0℃ to +50℃
Non-operating: -40℃ to +70℃
Cooling Method
Fan cooled
Humidity Range
0℃ to +30℃: ≤95％RH
+30℃ to +40℃: ≤75％RH
+40℃ to +50℃: ≤45％RH
Altitude
Operating: under 3,000 m
Non-operating: under 15,000 m
Physical Characteristics
Dimensions
[4]
Width× Height× Depth=361.6 mm× 179.6 mm× 130.8 mm
Weight
[5]
Package Excluded
3.9 kg ± 0.2 kg
Package Included
4.5 kg ± 0.5 kg
Calibration Interval
The recommended calibration interval is 18 months.
Electromagnetic Compatibility and Safety
