RIGOL Chapter 16 Specifications
DS2000E User’s Guide
16-2
Time Base Mode
Y-T, X-Y, Roll
Number of X-Ys
1 path
Waveform Capture Rate
[2]
50,000 wfms/s (dots display)
Vertical
Bandwidth
(-3 dB) (50 Ω)
DS2102E: DC to 100 MHz
DS2202E: DC to 200 MHz
Single-shot Bandwidth (50 Ω)
DS2102E: DC to 100 MHz
DS2202E: DC to 200 MHz
Vertical Resolution
8 bits
Vertical Scale
[3]
When the input impedance is 50 Ω: 500 μV/div
to 1 V/div
When the input impedance is 1 MΩ: 500 μV/div
to 10 V/div
Offset Range
When the input impedance is 50 Ω:
500 μV /div to 50 mV/div: ± 2 V
51 mV/div to 200 mV/div: ± 10 V
205 mV/div to 1 V/div: ± 12 V
When the input impedance is 1 MΩ:
500 μV /div to 50 mV/div: ± 2 V
51 mV/div to 200 mV/div: ± 10 V
205 mV/div to 2 V/div: ± 50 V
2.05 V/div to 10 V/div: ± 100 V
Bandwidth Limit
[1]
DS2102E: 20 MHz
DS2202E: 20 MHz/100 MHz
Low Frequency Response
(AC Coupling,
-3 dB)
≤5 Hz (on BNC)
Calculated Rise Time
[1]
DS2102E: 3.5 ns
DS2202E: 1.8 ns
DC Gain Accuracy
[3]
± 2% of full scale
DC Offset Accuracy
± 0.1 div± 2 mV± 1% of offset value
Channel-to-Channel Isolation
DC to maximum bandwidth: >40 dB
