RIGOL Chapter 2 Front Panel Operations

2-60 DSG3000 User’s Guide

Filename Prefix

Press Storage  Name Prefix to select “Prefix State” or “Edit Prefix”.

1. Prefix State

Press Prefix State to select “On” or “Off” to enable or disable the prefix edited.

When “On” is selected, the edited prefix will be added into the filename input

box automatically when saving file.

2. Edit Prefix

Press Edit Prefix to enter the filename input interface and you can use the

numeric keyboard to edit the prefix.

Disk Management

Press Storage  Disk Mgr to select “Format D” or “Disk Info”.

1. Format D

After selecting “D Disk”, press Format D  OK to format the local disk.

2. Disk Information

Press Disk Info to view the disk information including the disk name, type, file

system, used space and total space.

System Update

After selecting the update file in the USB storage device, press Storage  Update

to update the software of the RF signal generator.
