Rigol DSG3030 [93/148] System information

Chapter 2 Front Panel Operations RIGOL

DSG3000 User’s Guide 2-51

Unit

Press Unit to set the unit of the measurement value. The available units include dBm

and Watts.

NOTE: When the “relative measurement” is turned on, the available units are dB

and % and the default unit is dB.

System Information

Press Information and the system information of the USB power sensor currently

connected is displayed in the text display area of the user interface, including the

“Manufacturer”, “Model”, “SN” and “Version”.
