Rigol DSG3030 [41/148] Parameter zoom in mode

Chapter 1 Quick Start RIGOL

DSG3000 User’s Guide 1-23

Parameter Zoom-in Mode

In normal display mode, pressing the display switch key View at the left of the

screen can switch to the parameter zoom-in mode as shown in the figure below.

Figure 1-10 User Interface (Parameter Zoom-in Mode)
