Chapter 6 Specifications RIGOL
DSG3000 User’s Guide 6-3
Frequency Sweep
Operating mode
Step sweep (equally or logarithmically spaced frequency steps)
List sweep (the list of arbitrary frequency steps)
Sweep mode
Single, continuous
Sweep range
Full frequency range
Sweep shape
Triangle, ramp
Step change
Linear or logarithmic
Number of
points
Step sweep
2 to 65535
List sweep
1 to 6001
Dwell time
range
20ms to 100s
Triggering
Auto, trigger key, external, bus (GPIB, USB, LAN)
Spectral Purity
[3]
Harmonic
CW mode, 1MHz ≤ f ≤ 6GHz,
level ≤ +13dBm
<-30dBc
Sub harmonic
CW mode
f ≤ 3GHz
<-65dBc, <-80dBc (typ.)
3GHz < f ≤ 6GHz
<-52dBc, <-70dBc (typ.)
Non harmonic
CW mode, level > -10dBm, carrier offset > 10kHz
f ≤ 1.5GHz
<-64dBc, <-70dBc (typ.)
1.5GHz < f ≤ 3GHz
<-58dBc, <-64dBc (typ.)
3GHz < f ≤ 6GHz
<-52dBc, <-58dBc (typ.)
SSB phase
noise
CW mode, at 20kHz carrier offset, 1Hz measurement bandwidth
f = 100MHz
<-120dBc/Hz
f = 1GHz
<-108dBc/Hz, <-110dBc/Hz
(typ.)
f = 3GHz
<-102dBc/Hz, <-104dBc/Hz
(typ.)
f = 6GHz
<-96dBc/Hz, <-98dBc/Hz (typ.)
Residual FM
RMS value at f = 1GHz, CW
0.3kHz to 3kHz
<5Hz rms, <1Hz rms (typ.)
0.03kHz to 20kHz
<30Hz rms, <8Hz rms (typ.)
NOTE: [1] Except in the case when band1 is switched with another band.
[2] N is a factor used to help define certain specifications within the document.
[3] Without IQ-DSG3000 option.
