User Guide 20
Managing System Managing User Account
4
Managing User Account
With user account management, you can modify the username and password to refuse
illegal users.
Choose the menu System > User Account to load the following page.
Figure 4-1 Managing the User Account
Follow these steps to configure the user account:
1) Specify the user name, enter the old password, specify a new password and confirm
the new password.
User Name Create a user name for login. The length of user name should be less
than 16 characters which can contain only English letters, digits and
underscores.
Old Password Enter the old password of the switch. By default, the old password is
admin.
New Password Specify a new password for login. The length of password should be
less than 16 characters which can contain only English letters, digits and
underscores.
Confirm
Password
Retype the new password.
2) Click Apply.
