User Guide 78
Searching Help Help
1
Help
1.1 Overview
With the Help function, you can search for online help and view the information about the
utility.
1.2 Supported Features
Online Help
You can access the TP-Link support website and get the online user guide for the Easy
Smart Configuration Utility (the latest copy of this manual) and the products.
About
You can view the information about the utility, including the switch models supported by
the utility, the version of the utility software, and copyright information.
