- 54 -GA-8IMMT4 Motherboard
English
Flash BIOS Method Introduction
A. What is Q-Flash Utility?
Q-Flash utility is a pre-O.S. BIOS flash utility enables users to update its BIOS within BIOS
mode, no more fooling around any OS.
B. How to use Q-Flash?
a. After power on the computer, pressing <Del> immediately during POST (Power On Self Test) it
will allow you to enter AWARD BIOS CMOS SETUP, then press <F8> to enter Q-Flash utility.
CMOS Setup Utility-Copyright (C) 1984-2002 Award Software
Standard CMOS Features Load Fail-Safe Defaults
Advanced BIOS Features Load Optimized Defaults
Integrated Peripherals Set Supervisor Password
Power Management Setup Set User Password
PnP/PCI Configurations Save & Exit Setup
Frequency/Voltage Control Exit Without Saving
Top Performance
ESC:Quit :Select Item
F8: Q-Flash F10:Save & Exit Setup
Time, Date, Hard Disk Type...
Enter Q-Flash Utility (Y/N)? Y
b. Q-Flash Utility
Q-Flash Utility V3.07
Flash Type/Size : SST 49LF002A / 256K
Keep DMI Data : Yes
Space Bar:Change Value
Enter: Run ESC: Reset /: Select Item
Load BIOS from Floppy
Save BIOS to Floppy
Method 1 : Q-Flash
