Gigabyte GA-8IMMT4 [9/87] Chapter 1 introduction
![Gigabyte GA-8IMMT4 [9/87] Chapter 1 introduction](/views2/1047338/page9/bg9.png)
Introduction
English
- 5 -
Form Factor — 20.9cm x 24.3cm Micro ATX size form factor, 4 layers PCB(ver. 1.0)
— 19.5cm x 24.3cm Micro ATX size form factor, 4 layers PCB(ver. 1.1)
CPU — Socket 478 for Intel
®
Micro FC-PGA2 Pentium
®
4 processor
— Supports Intel
®
Pentium
®
4 (Northwood, 0.13 m) processor
— Intel Pentium
®
4 400MHz FSB
— 2nd cache depends on CPU
Chipset — Intel
®
Chipset 82845GL HOST/AGP/Controller
— Intel
®
ICH4 I/O Controller Hub
Memory — 2 168-pin SDRAM DIMM sockets
— Supports PC-133 SDRAM
— Supports only 3.3V SDRAM DIMM
— Supports up to 1.0GB SDRAM (Max)
I/O Control — ITE8702
Slots — 3 PCI slot supports 33MHz & PCI 2.2 compliant
On-Board IDE — 2 IDE controller on the Intel ICH4 PCI chipset provides
IDE HDD/CD-ROM with PIO, Bus Master (Ultra DMA33/ATA66/
ATA100) operation modes
— Can connect up to four IDE devices
On-Board Peripherals — 1 Floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M
and 2.88M bytes
— 1 Parallel port supports Normal/EPP/ECP mode
— 1 Serial port (COMA), 1 VGA port, COMB on Board
— 6 x USB 2.0/1.1 (2 x Rear, 4 x Front by cable)
— 1 Front Audio connector
On-Board VGA — Built in Intel 845GL Chipset
On-Board Sound — Sigmatel 9721 CODEC
— 1 Buzzer
— Line In / Line Out / Mic In / CD In / AUX In / Game Port
Chapter 1 Introduction
to be continued......
Features Summary
