- 8 -GA-8I865PE-L Motherboard
English
GA-8I865PE-L Motherboard Layout
RAM_LED
GA-8I865PE
KB_MS
COMACOMB
ATX_12V
SOC KET478
CPU_FAN
ATX
FDD
LPT
R_USB
Hyper Threading
SPDIF_IO
IR_CIR
PCI5
F_U SB1
F_U SB2
GAME
IDE1
IDE2
MIC_IN
USB
LAN
PWR_LED
CODEC
ITE8712
F_PANEL
BAT
PCI3
PCI4
BIOS
AUX_IN
CI
P4 Titan
SYS_FAN
INFO_LINK
CLR_PWD
F_AUDIO
ICH5
PCI2
SUR_CEN
PCI1
DDR3
DDR1
DDR2
CD_IN
Intel
®
865PE
AGP
Kinnereth-R
LINE_IN
LINE_OUT
DDR4
2X_DET
SATA1
SATA0
CLR_CMOS
