- 74 -GA-8I865PE-L Motherboard
English
Part Two:
Updating BIOS with Q-Flash
™
Utility on Single-BIOS Motherboards.
This part guides users of single-BIOS motherboards how to update BIOS using the Q-Flash
™
utility.
Entering the Q-Flash
™
utility:
Step1: To use the Q-Flash
™
utility, you must press Del in the boot screen to enter BIOS menu.
CM OS Setup Utility-Copyright (C) 1984-2002 Award Software
}Standard CM OS Features Top Performance
}Advanced BIOS Features Load Fail-Safe Defaults
} Integrated Peripherals Load Optimized Defaults
} Pow er M anagement Setup Set Superv isor Password
}PnP/PCI Configurations Set User Password
}PC H ealth Status Save & Exit Setup
} Frequency/Voltage Control Ex it Without Saving
ESC:Quit higf:Select Item
F8: Q-Flash F10:Sav e & Exit Setup
Time, Date, Hard Disk Type...
2. Press F8 on your keyboard and then Y button to enter the Q-Flash
™
utility.
CM OS Setup Utility-Copyright (C) 1984-2002 Award Software
}Standard CM OS Features Top Performance
}Advanced BIOS Features Load Fail-Safe Defaults
} Integrated Peripherals Load Optimized Defaults
} Pow er M anagement Setup Set Superv isor Password
}PnP/PCI Configurations Set User Password
}PC H ealth Status Save & Exit Setup
} Frequency/Voltage Control Ex it Without Saving
ESC:Quit higf:Select Item
F8: Q-Flash F10:Sav e & Exit Setup
Time, Date, Hard Disk Type...
Enter Q-Flash Utility (Y/N) ? Y
