Technical Reference
- 67 -
English
Step 2: Press F8 button on your keyboard and then Y button to enter the Q-Flash
™
utility.
Exploring the Q-Flash
™
/Dual BIOS utility screen
The Q-Flash
™
/Dual BIOS utility screen consists of the following key components.
AMIBIOS SIMPLE SETUP UTILITY - VERSION 2.00
(C ) 2001 American M egatrends, Inc. All Rights Reserv ed
STANDARD CMOS SETUP INTEGRATED PERIPHERALS
BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP
CHIPSET FEATURES SETUP SUPERVISOR PASSWORD
POWER MANAGEMENT SETUP USER PASSWORD
PNP / PCI CONFIGURATION IDE HDD AUTO DETEC TION
LOAD FAIL-SAFE DEFAULTS SAVE & EXIT SETUP
LOAD OPTIMIZED DEFAULTS EXIT WITHOUT SAVING
ESC: Quit hifg: Select Item F5: Old Values F6: Fail-Safe Values
F7: Optimized Values F8: Dual BIOS/Q-Flash F10:Sav e & Exit
Load Fail-Safe Defaults
ENTER DUAL BIOS/Q-FLASH UTILITY (Y/N) ? Y
Dual BIOS Utility
Boot From......................................... Main Bios
Main ROM Type/Size........................ SST 49LF003A 256K
Backup ROM Type/Size.................... SST 49LF003A 256K
Wide Range Protection Disable
Boot From Main Bios
Auto Recovery Enable
Halt On Error Disable
Copy M ain ROM Data to Backup
Load Default Settings
Sav e Settings to C MOS
Q-Flash Utility
Load M ain BIOS from Floppy
Load Backup BIOS from Floppy
Sav e Main BIOS to Floppy
Sav e Backup BIOS to Floppy
Enter : Run hi:Mov e ESC:Reset F10:Power Off
Dual BIOS utility bar
Q-Flash
TM
utility title
bar
Action bar
Task menu for
Q-Flash
TM
utility
Task menu for
Dual BIOS utility
