Gigabit Unmanaged Switch
07Introduction
The rear panel of TL-SG1016 is shown as the following figure.
Figure 1-10 Rear Panel of TL-SG1016
Power
Socket
Grounding
Terminal
The rear panel of TL-SG1024D is shown as the following figure.
Figure 1-11 Rear Panel of TL-SG1024D
Power
Socket
Grounding
Terminal
The rear panel of TL-SG1016D is shown as the following figure.
Figure 1-12 Rear Panel of TL-SG1016D
Power
Socket
Grounding
Terminal
The rear panel of TL-SG1008 is shown as the following figure.
Figure 1-13 Rear Panel of TL-SG1008
Grounding
Terminal
Power
Socket
