Gigabit Unmanaged Switch
17Appendix B Specications
Appendix B Specifications
Item Content
Standards
IEEE802.3i, IEEE802.3u, IEEE802.3ab
IEEE802.3x (except TL-SG1048)
IEEE802.1p (for TL-SG1008MP/TL-SG1008)
IEEE802.3af (for TL-SG1008MP), IEEE802.3at (for TL-SG1008MP)
Transmission Medium
10Base-T UTP/STP of Cat. 3 or above(maximum 100m)
100Base-TX 2-pair UTP/STP of Cat. 5 or above (maximum 100m)
1000Base-T 4-pair UTP/STP of Cat. 5e or above (maximum 100m)
Safety & Emissions FCC, CE
Protocol CSMA/CD
PoE Power on RJ45
(Only forTL-SG1008MP)
Power+: pin 3 & pin 6
Power -: pin 1 & pin 2
Transfer Method Store-and-Forward
MAC Address Learning Automatically learning, automatically aging
Frame Forward Rate
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
1000Base-T: 1488095pps/Port
LEDs
Power, Link/Act (TL-SG1048)
Power, Link/Act, 1000Mbps (TL-SG1024/TL-SG1024D/TL-SG1016/TL-SG1016D/
TL-SG1008)
Power, PoE MAX, 1000Mbps, Link/Act, PoE Status (TL-SG1008MP)
Operating Temperature 0 to 40
℃
(32 to 104
℉
)
Storage Temperature -40 to 70
℃
(-40 to 158
℉
)
Operating Humidity 10% to 90%RH Non-condensing
Storage Humidity 5% to 90%RH Non-condensing
