- 2 -
Ordering Information
Series name DPA: Delta DPA series pressure sensor
1
2
Measurable pressure range
01: -100kPa ~ 100kPa
10: -100kPa ~ 1,000kPa
3
Output types
N: NPN output + 4 ~ 20mA; P: PNP output + 4 ~ 20mA
M: NPN output + 1 ~ 5V; Q: PNP output + 1 ~ 5V
4
Pressure pore types
P: Outer pore PT 1/8, inner pore M5
N: Outer pore NPT 1/8, inner pore M5
G: Outer pore G 1/8, inner pore M5
Electrical Specifications
Power supply
Voltage range 12 ~ 24V DC +/- 10% no isolation
Power consumption 40mA Max.; current output type 60mA Max.
Pressure
measurement
Pressure type Non-corrosive gas, gauge type
Measurable range
DPA01: -100kPa ~ 100kPa
DPA10: -100kPa ~ 1,000kPa
Max. durable pressure
DPA01: 200kPa
DPA10: 1,500kPa
Accuracy +/- 3% entire process
Temperature inaccuracy +/- 2% entire process
Display
Setup display 2-line LCD display, 4 digits for measured value and 3.5 digits for setup display
Status display LCD output status display
Display mode 3 colors for different modes
Cycle 100ms, 250ms, 500ms, 1,000ms
Output
Number of outputs Built-in 2 NPN or PNP transistor digital outputs and 1 analog output
Transistor output
NPN: Max. durable pressure 30V/100mA, residual voltage 1.5V
PNP: Max. durable pressure 30V/100mA, residual voltage 1.5V
Analog output
1 ~ 5V: Min. output load resistance 1,000Ω
4 ~ 20mA: Max. output load resistance 400Ω; linear inaccuracy < 2% entire process
Response time 2ms, 4ms, 10ms, 30ms, 50ms, 100ms, 250ms, 500ms, 1,000ms, 5,000ms
Output inaccuracy Linear inaccuracy: < +/- 2% entire process
Pore size
P Outer pore PT 1/8, inner pore M5
N Outer pore NPT 1/8, inner pore M5
G Outer pore G 1/8, inner pore M5
Shock immunity 10 ~ 500Hz, 10mm 3 axes for 2 hours
Vibration immunity Max. 100m/ s
2
3 axes 6 directions, 3 times each
Ambient temperature 0°C ~ +50°C
Storage temperature -20°C ~ +65°C
Altitude < 2,000m
Ambient humidity 35% ~ 80% RH (non-condensing)
