16 | English
1 609 92A 275 | (17.12.15) Bosch Power Tools
Assembly
Inserting/Replacing the Battery
Alkali-manganese batteries are recommended for the measuring tool.
– Press the latch 9 of the battery lid outward and open the battery lid 11.
When inserting the battery, pay attention to the correct polarity according to the rep-
resentation on the inside of the battery compartment.
When the battery low indicator c appears for the first time on the display 7, the meas-
uring tool can still be operated for approx. 3 h.
If the measuring tool is not used for a long period of time, the battery must be
removed. The battery can corrode or discharge itself over long periods.
Receivable rotation speed
>200 min
-1
>200 min
-1
Measuring accuracy
2) 3) 4)
– Setting “fine”
– Setting “medium”
±1mm
±3mm
±1mm
±3mm
Operating temperature
– 10 °C ... +50 °C – 10 °C ... +50 °C
Storage temperature
– 20 °C ... +70 °C – 20 °C ... +70 °C
Battery
1 x 9 V 6LR61 1 x 9 V 6LR61
Operating time, approx.
50 h 50 h
Weight according to
EPTA-Procedure 01:2014
0.25 kg 0.25 kg
Dimensions
(length x width x height)
148 x 73 x 30 mm 148 x 73 x 30 mm
Degree of protection
IP 65 (dust-proof and
protected against
powerful water jets)
IP 65 (dust-proof and
protected against
powerful water jets)
Laser Receiver LR 1 LR 1 G
1) The working range (radius) can be reduced due to unfavourable ambient conditions (e.g. direct
sunlight).
2) depends on clearance between laser receiver and rotational laser level
3) dependent on laser class and laser type of the rotational laser level
4) The measuring accuracy can be impacted by unfavourable environmental conditions (e.g. direct
sun irradiation).
The measuring tool can be clearly identified with the serial number 10 on the type plate.
OBJ_DOKU-27392-004.fm Page 16 Thursday, December 17, 2015 4:56 PM
