Attaching with the Holder (see figure A)

With the holder 17, the measuring tool can be fastened to a construction laser measur-

ing rod 15 (accessory) as well as to other auxiliary tools with a width of up to 65 mm.

– Screw the holder 17 to the retainer opening 12 on the rear side of the measuring

tool with fastening screw 16.

– Loosen the locking screw 13, slide the holder onto the construction laser measur-

ing rod 15, for example, and retighten the locking screw 13.

The upper edge 14 of the holder is located at the same height as the centre mark 5

and can be used for marking of the laser beam.

Attaching with the Magnet (see figure B)

When a positive-lock attachment is not absolutely required, the measuring tool can be

attached to steel parts via the face side using the magnet plate 4.

Maintenance and Service

Maintenance and Cleaning

– Keep the measuring tool clean at all times.

– Do not immerse the measuring tool in water or other fluids.

– Wipe off debris using a moist and soft cloth. Do not use any cleaning agents or sol-

vents.

After-sales Service and Application Service

Our after-sales service responds to your questions concerning maintenance and re-

pair of your product as well as spare parts. Exploded views and information on spare

parts can also be found under: www.bosch-pt.com

Bosch’s application service team will gladly answer questions concerning our prod-

ucts and their accessories.

In all correspondence and spare parts orders, please always include the 10-digit arti-

cle number given on the nameplate of the product.

Great Britain

Robert Bosch Ltd. (B.S.C.)

P.O. Box 98

Broadwater Park

North Orbital Road

Denham

Uxbridge

UB 9 5HJ
