2.3 Device fixing and Installation

Procedure

1 Power on the master machine and slave machine, adjust the wing arms. Ensure that the wing arms are in the

same line and the distance between the wings is 60 mm. Make the wings to be in the OFF state.

2 Make sure the infrared correlation tubes on both sides align with each other.

3 Make marks: Mark the screw hole centers of the base and chassis base edges on the ground.

4 Drill holes: Move away the chassis and get ready a hammer drill and a 14 mm drill bit. Drill a hole with the depth

of 80 mm in the screw hole center marks. Alternatively, drill holes according to installation hole positions. For

devices, see Figure 2-3 for installation hole positions. The unit of data in the figures is mm.

5 Apply screw glue to the outer surface and threads of the expansion screws, insert expansion screws, and fix the

master machine and slave machine in the marked positions. Use a level checker (or spirit level) to check

whether the installation ground foundation is in correct level. If not, use a pad for adjustment.

Note: It is recommended that a canopy be set up out of door. And it is recommended to set guard lines to prompt the

users to swipe cards outside the guard lines.
