IVT PL-560-RC [13/108] Dust extraction

Instruction manual

and screws. Use only cutter blades that have been

properly checked and are approved for use at the speed

specied on the planer.

∙ While planing, the planer must always lie at at all

points.

∙ Always use both hands to guide the planer.

∙ Move the planer evenly forward over the workpiece

to increase the useful life of the planer cutters and

reduce hazards.

∙ Never put your ngers in the chip discharge hole.

If the discharge hole is blocked, pull out the plug

and remove the chips from the discharge hole with a

wooden stick.

∙ On completing work do not put the planer down

until the cutter shaft has stopped rotating.

∙ Before using the planer for the rst time check the

setting and seating of the cutter blade and cutter shaft.

UNPACKING

When unpacking, check to make sure that all

components are included. Refer to the drawings on this

manual. If any parts are missing or broken, please call

an IVT assistance center.

DUST EXTRACTION

Dust extraction prevents large

accumulations of dust, high

concentrations of dust in the ambient air,

and facilitates disposal.

For long periods of working with wood or for commercial

use on materials that produce dust that is detrimental

to health, the machine is to be connected to a suitable

external dust extraction device.

INITIAL OPERATION

Always use the correct supply voltage: the power supply

voltage must match the information quoted on the tool

identication plate.

SWITCHING ON / OFF [F1]

Switching On

To switch the machine ON, keep the lock-off button (2)

depressed and press the On/Off switch (1).

Switching Off

To switch the machine OFF, release the On/Off switch

(1).

OPERATING INSTRUCTIONS

Setting cut depth [F2]

Turn the additional handle with cut-depth set (6) to the

right as far as it stops.

∙ Put the planer on a at surface and turn the

additional handle with cut-depth set (6) to the left until

the planer sole plate lies at on the surface and the «0»

mark on the knob is level with the mark on the housing.

To set the desired cut depth turn the knob to the right for

any cut depth up to a permitted maximum of 1 mm. The

marks on the setting knob serve as a guide.

Planing

First, place the forward sole plate of the planer at on

the surface of the workpiece, but so that the cutters do

not come into contact with it.

Start the planer up and wait for the cutters to reach full

speed.

Then push the planer carefully forward. When starting

planing, apply pressure to the front end of the planer

and, when nishing planing, to the rear end.

Planing is easier if the workpiece is set at an angle, so

that you work forward and downwards.

The speed and cut depth determine the surface quality.

The planer cuts evenly at a speed which prevents

jamming through chips.

For rough-cutting the cut depth can be increased, while

for optimum surface quality the cut depth should be

reduced and the planer moved more slowly.

Rabbeting [F3]

To make a stepped cut, use the parallel guide (8).

∙ Draw a cutting line on the workpiece. Insert the

parallel guide (8) into the hole in the front of the tool.

∙ Align the blade edge (20) with the cutting line.

∙ Adjust the parallel guide (8) until it comes in

contact with the side of the workpiece, then secure it by

tightening the screw (21).

When planing, move the tool with the edge fence ush

with the side of the workpiece. Otherwise uneven

planing may result.

Bevelling and chamfering edges [F4]

The V-groove (5) on the bottom of the front sole plate

makes it possible to chamfer the edges of the workpiece.

∙ Place the 90° V-groove (5) on the edge of the

workpiece and move it along it.
