3.3 Main connection

The sauna heater must be connected to the mains by a qualified electrician and in compliance with current regulations.

Sauna heater is connected with a semi-permanent connection. Use H07RN-F (60245 IEC 66) cables or a corresponding

type. Other output cables (signal lamp, electric heating toggle) must also adhere to these recommendations. Do not use

PVC insulated cable as a connection cable for the sauna heater.

If the connection box is located at 500mm distance from the heater, the maximum height is 1000mm from the floor. (Image

3 on page 10: Location for the connecting box).

Sauna heater insulation resistance: The sauna heater heating elements may absorb moisture from air, e.g. during storage.

This may cause bleeder currents. The moisture will be gone after a few heating sessions. Do not connect the heater power

However, always adhere to the effective electrical safety regulation when installing the sauna heater.

Heater connection

mm

2

60245 IEC 66

mm

2

Fuse

A

Heater connection

A

4,5

5 x 1,5

3 x 10

4 x 2,5

3 x 16

3 x 4,0

1 x 20

3.4 Electric heating toggle

Electric heating toggle applies to homes with an electric heating system.

Sauna heater has connections (marked N - 55) for controlling the electric heating toggle. Connectors N - 55 and the heating

elements are simultaneously live (230V). The sauna heater thermostat also controls the heating toggle. In other words,
