4. Spare parts for Ring Wall ST-electric sauna heater
Parts Product
number
Product title SKSR ST 45 SKSR ST 60 SKSR ST 80
1 4071153 Basic grate 1 1 1
2 5509028 Clock
OYKO 3
1 1 1
3 5408013 Thermostat
OLCH 1
1 1 1
4 7812550 Mains connector
NLWD 1-1
1 1 1
5 7712000 Cable clamp NKWA 1 1 1 1
6 4309555 Knob YWWA 11-2 2 2 2
7 6101741 Switch 1 1 1
8 7306008 Switch protective rubber 1 1 1
9 5716203 Contactor Finder 1 1 1
10 4316222 Heating element SEPC 63
1500W/ 230V
3
10 4316221 Heating element SEPC 64
2000W/230V
3
10 4316220 Heating element SEPC 65
2670W/230V
3
11 7513002 Screw
M5 x 10
3 3 3
Table 3. Spare parts for Ring Wall ST
Product Manual Ring Wall ST
13
