Helo RING WALL 60 ST [2/14] Product manual ring wall st
![Helo RING WALL 80 ST [2/14] Product manual ring wall st](/views2/1518551/page2/bg2.png)
Contents
1. Quick instructions for use of the sauna heater 3
1.1 Check before taking a sauna bath 3
1.2 Operation of the sauna heater controls 3
2. Information for users 3
2.1 Sauna room 3
2.2 Recommended sauna room ventilation 4
2.3 Heating the sauna 4
2.4 Sauna heater stones 5
2.5 Sauna heater controls 6
2.5.1 Timer switch 6
2.5.2 Thermostat 6
2.6 Electric heating toggle 7
2.7 If the sauna heater will not heat up 7
3 Instructions for heater installation 7
3.1 Preparing for sauna heater installation 7
3.2 Installation 7
3.2.1 Sauna heaters installation 8
3.3 Main connection 10
3.4 Electric heating toggle 10
3.5 Location the connection box for connection cable in 11
the sauna room 11
3.6 Wiring diagram 12
4. Spare parts for Ring Wall ST-electric sauna heater 13
5. ROHS 14
Images and table
Image 1 Sauna room ventilation 4
Image 2 Safety clearances 9
Image 3 Location for the connection box 11
Image 4 Switch diagram for the sauna heater 12
Table 1 Safety clearances 9
Table 2 Connection cable and fuse 10
Table 3. Spare parts for Ring Wall ST 13
Product Manual Ring Wall ST
2
