Monsher Kvazi 60 W [9/32] If the hood will operate in the recirculation mode then the air duct is not

9English

6.13 If the hood will operate in the recirculation mode, then the air duct is not

necessary. It is necessary to install the odor-absorbing carbon filter (optional) on

the T-shaped pin of a turbofan lid.

6.14 Install the outer panel of the chimney casing into the grooves on the hood

housing, and lift the inner one upwards to align the mounting holes with the bar

and connect the sides with 2 pan-head screws 2.9x9.5 (Fig. 4).

6.15 Ensure that the cooker hood is properly fastened. Supply and connect a power

cord to the mains power supply using a socket. To provide additional protection in

case of power supply voltage swings, connect the appliance using an additional 6А

circuit breaker.

7. INSTRUCTIONS FOR USE OF THE COOKER HOOD

7.1 The cooker hood with the mechanical switch has 3 fan speeds. You can select

low, medium or high-speed mode considering cooking evaporation output.

7.2 Switch the cooker hood on and select an appropriate operation mode prior

to cooking.

Allow it to operate for 3-5 min after cooking in order to exhaust residual evaporation

and odors.

7.3 On the bottom surface of the housing there is a button switch for selecting

of operating mode and switching on the light bulbs (Fig. 5):

Fig. 5

1 - low speed,

2 - medium speed,

3 - high speed,

0 - the fan is off.

The switch (with the symbol of a light bulb) is designed

to turn on the light bulbs in case of insufficiently

illuminated cooktop:

0 - light is off.

І - light is on.
