712 English Instruction Sheet
Page
13
Specifications
Specifications are based on a one year calibration cycle and
apply for ambient temperature from +18°C to +28°C unless
stated otherwise.
Note
Specifications on this Instruction Sheet apply to the 712
RTD Calibrators with serial number 7676001 or above.
Ohms Specifications
Ohms
Range
Input
Accuracy
4-Wire ±Ω
Output
Accuracy
± Ω
Allowable
Excitation (mA)
0.15 0.1 to 0.5 0.00Ω to
400.00Ω
0.1
0.1 0.5 to 3.0
400.0Ω to
1500.0Ω
0.5 0.5 0.05 to 0.8
1500.0Ω to
3200.0Ω
1 1 0.05 to 0.4
Allowable Excitation is for Output mode only. It shows the allowable
excitation current from an ohmmeter or RTD measurement device
connected to the calibrator.
Excitation current from 712: 0.2 mA.
Maximum input voltage: 30 V
