5
950969-01 24/10/17
Mod.2
¾ Regolare tempo e potenza (C) per l’operazione desiderata seguendo le indicazioni
riportate in tabella (T) di Fig.1
Puntatura e trazione di rondelle, chiodi e rivetti (D1)
Riscaldamento e ricalco lamiere (D2)
Rappezzatura (D3).
L In questa funzione il tempo di pausa è sso (ca. 0,5 sec.).
Spia di segnalazione protezione termica (E)
La spia accesa signica che la protezione termica è in funzione.
Aspetta nché il funzionamento è ripristinato e possibilmente aspetta ancora qualche
minuto.
Manutenzione
Spegni la saldatrice ed estrai la spina dalla presa d’alimentazione prima di effettuare
operazioni di manutenzione.
STUDDER
Torcia = controllare che il cavo non abbia tagli o abrasioni tali da aver scoperto i
conduttori interni.
Massa = controllare l’efcienza delle connessioni e del morsetto.
Manutenzione straordinaria effettuabile da personale esperto o qualicato in ambito
elettromeccanico periodicamente, in funzione dell’uso.
• Ispeziona l’interno della saldatrice e rimuovi la polvere depositata sulle parti elettriche
(usa aria compressa) e sulle schede elettroniche (usa una spazzola molto morbida o
dei prodotti appropriati). • Verica che le connessioni elettriche siano ben serrate e che i
cablaggi non abbiano l’isolante danneggiato.
EN
Instruction Manual
Read this instruction manual carefully before using the welding machine.
Resistance welding equipment, hereafter referred to as “welding machine”, is used for
industrial and professional applications.
Make sure that the welding machine is installed and repaired only by qualied persons or
experts, in compliance with the law and with the accident prevention regulations.
These instructions refer to the machine as delivered. In case instructions are not strictly
followed or not recommended accessories and/or tools are used, the user shall be
responsible for assessing the risks and consequences of such acts.
The operator should be properly trained to use the spot-welder safely and should be
informed of the risks connected with resistance welding procedures, related protection
measures and of emergency procedures.
Safety warnings
Make sure that the power socket to which the welding machine is connected is protected
by suitable safety devices (fuses or automatic switch) and that it is grounded.
Make sure that the plug and power cable are in good condition.
Before plugging into the power socket, make sure that the welding machine is switched off.
Switch the welding machine off and pull the plug out of the power socket as soon as
you have nished working.
Switch the welding machine off and pull the plug out of the power socket before:
connecting the welding cables, installing the continuous wire, replacing any parts in the
torch or wire feeder, carrying out maintenance operations, or moving it (use the carrying
handle on the welding machine).
Do not touch any electried parts with bare skin or wet clothing. Insulate yourself from the
electrode, the piece to be welded and any grounded accessible metal parts. Use gloves,
footwear and clothing designed for this purpose and dry, non-ammable insulating mats.
Use the welding machine in a dry, ventilated space. Do not expose the welding machine
to rain or direct sunshine.
Use the welding machine only if all panels and guards are in place and mounted correctly.
Do not use the welding machine if it has been dropped or struck, as it may not be safe.
Have it checked by a qualied person or an expert.
Eliminate any welding fumes through appropriate natural ventilation or using a smoke
exhauster. A systematic approach must be used to assess the limits of exposure to
welding fumes, depending on their composition, concentration and the length of exposure.
Do not weld materials that have been cleaned with chloride solvents or that have been
near such substances.
Use a welding mask with adiactinic glass suited for welding. Replace the mask if
damaged; it may let in radiation.
Wear reproof gloves, footwear and clothing to protect the skin from the rays produced
by the welding arc and from sparks. Do not wear greasy garments as a spark could set
re to them. Use protective screens to protect people nearby.
Some parts of the spot-welder (electrodes arms and nearby areas) may reach
temperatures of over 65°C: suitable protective clothing must be worn.
Metal-working gives off sparks and splinters. Wear safety goggles with protective side
eye guards.
Welding sparks can trigger res.
Do not weld or cut anywhere near inammable materials, gasses or vapours.
Do not weld or cut containers, cylinders, tanks or piping unless a qualied technician or
expert has checked that it is possible to do so, or has made the appropriate preparations.
EMF Electromagnetic Fields
Welding current creates electromagnetic elds (EMF) near the welding circuits and
the welder. Electromagnetic elds may interfere with medical prostheses such as
pacemakers.
Suitable and sufcient measures should be implemented to protect those operators
having such aids. For instance, they should not be allowed to enter that area where
welding equipment is used. Any operator having such aids should consult their doctor
before coming close to an area where welding equipment is used.
This device meets the specic requirements of the product technical standard and is
intended for professional use in an industrial environment only. Compliance to expected
limits for human exposure to electromagnetic elds at home is not ensured.
Follow these strategies to minimise exposure to electromagnetic elds (EMF):
Do not place your body between the welding cables. Both welding cables should be on
the same side of your body.
Twist both welding cables together and secure them with tape when possible.
Do not wrap the welding cables around your body.
Connect the earth cable to the workpiece as close as possible to the area to be welded.
Keep your head and trunk as far as possible from the welding circuit. Do not work close to
the welder, or seated or leaning on it. Minimum distance: Fig. 7 Da = cm 50; Db = cm.20
Class A equipment
This equipment has been designed to be used in professional and industrial environments.
If this equipment is used in domestic environments and those directly connected to a
low voltage power supply network which supplies buildings used for domestic purposes,
it may be difcult to ensure compliance to electromagnetic compatibility as the result of
conducted or radiated disturbances.
Welding in conditions of risk
If welding needs to be done in conditions of risk (electric discharges, suffocation, the
presence ofinammableorexplosivematerials), make sure that an authorised expert
evaluates the conditions beforehand. Make sure that trained people are present who
can intervene in the event of an emergency. Use the protective equipment described in
5.10; A.7; A.9 of the IEC or CLC/TS 62081 technical specication.
If you are required to work in a position raised above ground level, always use a safety
platform.
Additional warnings
It is dangerous to use the spot-welder for any other purpose than that for which it is
designed (spot resistance welding).
Place the welding machine on a at stable surface, and make sure that it cannot move.
It must be positioned in such a way as to allow it to be controlled during use but without
the risk of being covered with welding sparks.
Do not lift the welding machine. No lifting devices are tted on the machine.
Do not use cables with damaged insulation or loose connections.
Description of the welding machine
Movable resistance welding system (spot-welder) with digital microprocessor control.
It allows numerous types of hot working and spot-welding on sheet metal and is made
specically for the vehicle bodyshop and sectors with similar types of working.
Main parts Fig.1 Mod.1
C) Timer increasing/decreasing values
E) Heat cut-out signal (resets automatically).
F) Timer display
G) Stand-by / on switch
G1) Stand-by / on indicator
Main parts Fig.1 Mod.2
A) Tool-function selector.
B) Timer/power switch on display.
C) Timer/power increasing/decreasing values
D1) Studder.
D2) Plate heater.
D3) Patching.
E) Heat cut-out signal (resets automatically).
B1) Timer display
B2) Power display
F) Timer/power display
G) ON / OFF switch
Technical data
A data plate is afxed to the welding machine. Fig. 2 shows an example of this plate.
A) Constructor name and address
E) European reference standard for the construction and safety of welding equipment.
B) Symbol of delivered current: alternate / frequency.
