17
• To prevent a freezing of the discharge pipe please
isolate the complete discharge pipe up to the sewer
level.
• Directly above the swing check valve (Saniboy I R,
Saniboy II and Sanimaster have an integrated swing
check valve) mount a gate valve into the discharge
pipe.
• Saniboy I, Saniboy G and Sanimaster G have no in-
tegrated swing check valve. Mount a swing check
valve DN 80 on the top of the discharge flange of the
Saniboy I and a gate valve above it. If you use a DN
80 discharge pipe mount instead of the supplied DN
80 / DN 100 elastic union piece a DN 80 / DN 80
elastic union piece (available as accessory).
Mount a swing check valve and a gate valve on top of
the 90° elbow of the Saniboy G and Sanimaster G
behind.
• For a trouble free operation of the pneumatic level
control it is absolutly necessary that the pressure
hose between tank and control box is installed with-
out loops, bending and constantly rising.
• Cut off the blanked off end of the air vent and con-
nect a DN 70 vent pipe to the tank by means of the
flexible connection supplied. The vent pipe should be
led out into the open air in accordance with local
regulations.
• Mount the supplied pump controller flood protected
on the wall in accordance with local regulations.
• A manual diaphragm pump is available as an acces-
sory. The pump is connected to the 1“ tank port.
The manual diaphragm pump is used for draining the
tank in the event of pump failure. Above the dia-
phragm pump must be fitted with a non-return valve
on the discharge side. To facilitate service of the dia-
phragm pump, it is advisable to fit a 1“ isolating valve
to the tank port. The pipe must conduct over the
sewer level, that means constantly rising over that
niveau and subsequently as a loop directly to the col-
lecting conduit.
8. Start-Up
Never let the pump run dry for a long time of period,
as it will destroy the pump (danger of overheating).
Before starting the disposal unit make sure that all isolat-
ing valves are open and check that the unit runs satisfac-
torily. The drain screw at the swing check valve housing is
used for draining the discharge pipe between swing
check valve and gate valve (only models Saniboy I R,
Saniboy II and Sanimaster).
When the drain screw is tightened, the swing check valve
is forced open, thus allowing the liquid in the discharge to
drain into the tank. During normal operation, the screw
should be loosened completely.
Make sure that the correct phase sequence was proofed
at the 3-ph models (see 6.3.).
Turn the operation switch into the position "Auto".
In combination with the pneumatic level control the pump
starts and stops according to the liquid level in the tank.
9. Maintenance and Repair
In case of a defect of the pump, a repair shall be car-
ried out only by the manufacturer or through an author-
ized workshop. Modifications of the pump must be con-
firmed by the manufacturer. Only HOMA spare parts shall
be used.
In accordance with the product liability law we point
out that we shall not be liable for damages caused by our
product due to unauthorized repair by persons other than
the manufacturer or an authorized workshop or due to the
use of spare parts other than original HOMA parts. The
same product liability limitations are valid for accessories.
Before maintenance or repair disconnect the pump
from the power supply to avoid accidental starting of the
pump!
Before maintenance or repair make sure that all rotat-
ing parts stand still!
Before carrying out maintenance and service, the
pump must be thoroughly flushed with clean water. Rinse
the pump parts in clean water after dismanteling.
At pump types with oil chamber an overpressure can
escape with loosening of the oil chamber control screw.
Screw only when pressure balance took place.
Pumps running under normal operation conditions should
be inspected at least once a year. If the pumped liquid is
very muddy or sandy or if the pump is operating continu-
ously, the pump should be inspected every 1.000 operat-
ing hours.
For long and trouble-free operation of the pump, following
points should be checked regularly:
- Nominal current (A):
Check with amp-meter.
- Pump parts and impeller:
Check for possible wear.
Replace defective parts.
- Ball bearings: Check the shaft for noisy or heavy opera-
tion (turn the shaft by hand). Replace defective ball bear-
ings. A general overhaul of the pump is usally required in
case of defective ball bearings or poor motor function.
This work must be carried out by an authorized
service workshop.
- Cable entry
: Make sure that the cable entry is watertight
and that the cables are not bent sharply and/or pinched.
Additionally at pump types with oil chamber:
- Oil level and oil condition in oil chamber:
Put the pump in horizontal position, so that the screw of
the oil chamber is above (at larger pumps: one of both
screws). Remove the screw and infer a small quantity of
oil. The oil becomes greyish white like milk if it contains
water. This may be the result of defective shaft seal.
In this case leave the condition of the shaft seals by a
HOMA Service to examine.
The oil should be replaced after 3000 operating hours.
Oil type: Shell Tellus C22, degradable HOMA-Atox (avail-
able on request). Used oil is to be disposed accordingly.
Servicing Contract
For a regular expert execution of all necessary mainte-
nance and inspection we recommend the conclusion of a
servicing contract by our HOMA Service. Please contact
our HOMA customer service.
