![Homa Saniboy G 180-16 D [32/36] Spare part list for submersible pump](/views2/1549702/page32/bg20.png)
32
15.3. Ersatzteilliste für Pumpe
ACHTUNG: Die untenstehende Liste enthält Teile, die
nicht in jedem Pumpentyp vorhanden sind. Deshalb bei
Ersatzteilbestellung bitte immer angeben:
- Pumpentyp
- Baujahr (siehe Typenschild auf der Pumpe)
- Zeichnungsposition (xx : Genaue Positionsnummer bitte
aus der Ersatzteilzeichnung entnehmen und bei
Bestellung angeben, siehe unten)
- Artikelbezeichnung (siehe unten)
- Gewünschte Stückzahl
Pos. Bezeichnung Pos. Bezeichnung
23 Schneidkopf 723 Gewindeflansch
50 Schneidring 731 Schlauchtülle
101 Pumpengehäuse 732.01 Halter f. Dichtungs-
überwachung
135 Schleisswand 732.02 Halter f. Dichtungs-
überwachung
143 Saugsieb 739 Festkupplung
149 Diffusor 750 Doppelmuffe
151 Außenmantel 752 Ring
162 Saugdeckel 811 Motorgehäuse
163 Druckdeckel 812 Motorgehäusedeckel
164 Putzlochdeckel 814 Stator mit Wicklung
172 Rückführstufe 819 Welle mit Rotor
183 Stützfuß 822.01 Motorlagergehäuse
185 Siebboden 822.02 Motorlagergehäuse
230.xx Laufrad 824.xx Anschlussleitung
320.01 Kugellager 826.xx Kabeleinführung
320.02 Kugellager 827.xx Knickschutztülle
360 Lagerdeckel 834.xx Kabeldurchführung
410 Dichtklappe 835.xx Motoren-Klemmbrett
411.xx Dichtring 836.xx Klemmleiste
412.xx O-Ring 837 Betriebskondensator
420 Wellendichtring 838 Schaltgerät
420.01 Wellendichtring 838.09 Startrelais
420.02 Wellendichtring 838.45 Schwimmerschalter
433 Gleitringdichtung 839.01 Flachsteckhülse
433.01 Gleitringdichtung 839.04 Durchführung mit Siche-
rungsblech
433.02 Gleitringdichtung 839.05 Potentialausgleichs-
klemme
502 Spaltring 839.09 Kabelschuh, isoliert
504 Distanzring 839.10 Kabelschuh, isoliert
531 Entlastungsklemme 839.11 Klemmbügel
550.xx Stützscheibe / Paß-
scheibe
839.12 U-Scheibe
552 Spannscheibe 900.xx Ringmutter / Sonder-
schrauben
554.xx Unterlegscheibe 901 Sechskantschraube
560 Spannstift 902 Gewindebolzen
561 Halbrundkerbnagel 903.xx Verschlussschraube
571 Klemmbügel 904 Gewindestift
576 Griff 909 Stellschraube
689.xx Isolierplatte 914.xx Zylinderschraube
690.01 Elektr. Dichtungsüber-
wachung für Dichtungs-
raum
922 Sechskantmutter
690.02 Elektr. Dichtungsüber-
wachung für Klemm-
raum
930.xx Zahnscheibe
702 Ablaufrohr 932.xx Sicherungsring
704 Zulaufrohr 940 Paßfeder
719 Schrumpfschlauch 950 Ausgleichsscheibe
720 Anschlusswinkel 90° 970 Typenschild
721 Schlauchverschrau-
bung
990.xx Motoröl
722 Anschlussstutzen 999.xx Ersatzteile für Schaltge-
rät
15.3. Spare part list for submersible pump
ATTENTION:
The following list contains parts that do
not correspond to every pump type. For spare part or-
ders, please always give:
- Pump type
- The year of construction (see the pump label)
- Position number (xx : take the exact position number
from the drawing of the specific pump model, see
hereafter)
- Part description (see hereafter)
- Required quantity
Pos. Part description Pos. Part description
23 Cutter head 723 Threaded flange
50 Cutter ring 731 Hose spigot
101 Pump housing 732.01 Electronic seal probe
holder
135 Wear plate 732.02 Electronic seal probe
holder
143 Suction sieve 739 Fixed half coupling
149 Diffuser 750 Socket for non-return
valve
151 Cooling jacket 752 Ring for non-return
valve
162 Suction cover 811 Motor housing
163 Pressure cover 812 Motor housing cover
164 Clean hole cover 814 Stator with winding
172 Feedback step 819 Motor shaft with rotor
183 Base stand 822.01 Lower bearing cover
185 Sieve bottom 822.02 Upper bearing cover
230.xx Impeller 824.xx Rubber sheated cable
320.01 Lower ball bearing 826.xx Cable leading-in socket
320.02 Upper ball bearing 827.xx Cable sleeve
360 Bearing cover 834.xx Cable inlet
410 Flap for non-return
valve
835.xx Motor terminal board
411.xx Sealing ring 836.xx Strip terminal
412.xx O- Ring 837 Operating capacitor
420 Radial shaft ring 838 Switch box
420.01 Lower radial shaft ring 838.09 Starter relay
420.02 Upper radial shaft ring 838.45 Float switch
433 Mechanical seal 839.01 Flat bushing
433.01 Lower mechanical seal 839.04 Lead-in of line lock-plate
433.02 Upper mechanical seal 839.05 Protective conductor
clamp
502 Wear ring 839.09 Cable socket, insulated
504 Ring 839.10 Cable socket, insulated
531 Cable relief clamp 839.11 Clamping ear
550.xx Supporting ring 839.12 Washer for 839.11
552 Clamping disc 900.xx
554.xx Washer 901 Hexagonal head screw
560 Dowel pin 902 Threaded bolt
561 Grooved drive stud 903.xx Locking screw
571 Clamping bow 904 Threaded pin
576 Handle 909 Adjusting screw
689.xx Insulating plate 914.xx Threaded pin
690.01 Electronic seal probe 922 Hexagonal head nut
690.02 Electronic seal probe 930.xx Tooth washer
702 Threaded tube for the
motor cooling jacket
932.xx Circlip
704 Threaded tube for the
motor cooling jacket
940 Fitting key
719 Shrink down plastic
tubing
950 Ball bearing disc
720 90° discharge elbow 970 Pump label
721 STA-hose 990.xx Motor oil
722 Discharge socket 999.xx Spare parts for switch
box
