Clarion CC4001U [3/11] Contents
![Clarion CC4001U [3/11] Contents](/views2/1552016/page3/bg3.png)
English
3 CC4001U
Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
Contents
1. FEATURES...................................................................................................................................... 3
2. PRECAUTIONS ............................................................................................................................... 4
3. SPECIFICATIONS ........................................................................................................................... 5
Package Contents............................................................................................................................ 5
4. OPERATIONS.................................................................................................................................. 6
Operation when using Clarion Rear Vision camera system ............................................................. 6
Troubleshooting................................................................................................................................ 6
5. INSTALLATION ............................................................................................................................... 7
Before installation............................................................................................................................. 7
Precautions when using two-sided tape for installation.................................................................... 7
Installing/Wiring the camera............................................................................................................. 7
6. WIRING............................................................................................................................................ 9
Wiring ............................................................................................................................................... 9
Connecting to a monitor ................................................................................................................. 10
■ High-performance 1/4” color CMOS sensor
■ 130º (horizontal) wide-angle lens provides extensive view to the rear
■ High-resolution glass lens for high image quality
■ Mirror-image inversion function presents optimum conditions for confirming rear view
(same right-left orientation as seen through a rear-view mirror)
■ Small size and weight for easy installation
■ Resists image smearing even when bright light is directed at the camera
■ Uses 12 V power, for easy power connection using vehicle’s reverse lamp, etc.
1. FEATURES
