12
TASCAM CD-9010
2 – Names and Functions of Parts
Menu structure
Press the MENU button to show the
MENU
screen.
The menu has five submenus.
1 PLAY
Settings related to playback
2 PROGRAM/CUE
Settings related to program playback and cue point
3 REMOTE
Settings related external remote settings
4
This menu item has been intentionally left blank.
5 SYSTEM
Settings related to the unit's system.
6 INFORMATION
Settings related to media information and the system version, and operating time confirmation.
The submenu items are as follows.
Main menu item Submenu item Function/Setting Reference
1
PLAY
1
AUTO CUE
Auto Cue P. 19
2
AUTO CUE LEVEL
Auto Cue level P. 19
3
AUTO READY
Auto Ready P. 20
4
INCREMENTAL PLAY
Incremental playback P. 20
5
ONLINE BACK CUE
Online back cue function P. 20
6
PLAY KEY FUNCTION
Function of PLAY and MONITOR buttons when online OFF P. 20
7
MONITOR PLAY STBY
STANDBY button function during monitoring playback P. 21
8
ONLINE PLAY STBY
STANDBY button function during online playback P. 21
9
REPEAT
Repeat playback function P. 21
10
EOM
EOM function P. 22
11
END CHECK
END CHECK function P. 22
12
PITCH
Pitch control function P. 23
13
PITCH %
Pitch control value P. 23
14
PITCH/TIME FIT
Time and pitch control playback P. 23
2
PROGRAM/CUE
1
PROGRAM EDIT
Edit programs P. 24
4
CUE LIST EDIT
Edit cue lists P. 26
7
CUE POINT LOAD
Cue point loading P. 27
3
REMOTE
1
FADER MODE
Fader function for TASCAM RC-9010/RC-9010S or other external
remote (sold separately)
P. 33
2
FADER START MODE
Fader start function for TASCAM RC-9010/RC-9010S or other
external remote (sold separately)
P. 33
3
FADER STOP MODE
Fader stop function for TASCAM RC-9010/RC-9010S or other
external remote (sold separately)
P. 33
4
FADER STOP ACT
Fader stop function action P. 34
5
FADER SCALE
Fader scale switching P. 34
6
OPERATION PANEL
Panel lock function P. 16
7
P.PORT P3/13 ASGN
Parallel remote connector 3-pin and 13-pin functions P. 35
8
SERIAL BAUD RATE
Serial remote connector transmission speed (baud rate) P. 34
