TASCAM CD-9010
17
4 – Playback
Monitoring and online playback
This unit has two playback modes: monitoring playback and
online playback. The outputs for the two playback modes can be
set to be independent of each other.
For example, you can use the monitoring playback mode for
broadcast use and on location to cue tracks and playback points
in advance to prepare for online playback from those points.
Monitoring playback
The
SYSTEM
menu
ONLINE FUNCTION
item must be set to
SWTCH.
OK
to enable monitoring playback. (See "Setting the online
function" on page 29.)
NOTE
If set as above, pushing the PLAY button will output the
•
playback signal to the monitoring destination.
If set as above, the playback signal will be output to the
•
monitoring destination when jogging and searching.
Starting monitoring playback
When stopped, in playback standby or during jog playback,
press the MONITOR button.
Status of outputs
Output Status
DIGITAL OUTPUT Off
LINE OUTPUTS Off
MONITOR OUTPUTS On
Online playback
The
SYSTEM
menu screen
ONLINE FUNCTION
item must be set to
AlwaysON
to enable online playback. (See "Setting the online
function" on page 29.)
Starting online playback
When in playback standby, monitoring playback or during jog
playback, press the PLAY button.
Status of outputs
Output Status
DIGITAL OUTPUT On
LINE OUTPUTS On
MONITOR OUTPUTS Off
NOTE
Set the SYSTEM menu MON MUTE ONLINE item to OFF to always
send the signal through the MONITOR OUTPUTS. (See "Muting
monitoring when online" on page 31.)
Setting the playback mode
Tracks on the CD can be played using one of the following three
playback modes.
Continuous playback mode (default setting)
The
•
indicator appears in the playback mode
area of the Home Screen.
The tracks on the
•
CD are played in track number order.
Single playback mode
The
•
indicator appears in the playback mode
area of the Home Screen.
Only the currently selected track is played before playback
•
stops.
Program playback mode
The
•
indicator appears in the playback mode
area of the Home Screen.
Tracks will be played in the order programmed in advance.
•
(See “Program playback” on page 24.)
The current playback mode appears in the playback mode area
of the Home Screen.
Use the PLAY MODE button to set the playback mode.
Press this button to cycle through the playback modes in the
following order.
CONTINUE mode
SINGLE mode
PROGRAM mode
NOTE
In this manual, unless otherwise specified, explana-
•
tions assume that the playback mode is set to CONTINUE
(continuous playback mode).
The playback mode setting is retained even when the power
•
is turned OFF.
