Tascam CD-9010 [30/40] Other settings and information display

TASCAM CD-9010

7 – Other settings and information display

Setting the master word clock

You can set the source to use for word synchronization.

1. Press the MENU button to open the

screen.

2. Open the

SYSTEM

menu.

3. Select

CLOCK MASTER

4. Press the DATA dial to move the cursor right to select the

setting.

5. Turn the DATA dial to set the master word clock.

•

INT

(default value): Use the unit's internal clock

•

EXT

: Synchronize with the word clock input through the

WORD SYNC IN connector

•

44.1K FIX

: Regardless of the file sampling frequency,

digital audio is always output at 44.1k FS.

6. After completing the setting, press the HOME button to

return to the Home Screen.

NOTE

The master clock setting is retained even when the power is

•

turned OFF.

Depending on the combination of master clock and

•

playback file sampling frequency settings, the digital output

sampling frequency will differ. (See "Master clock and digital

output combinations" below.)

Mono mix setting

You can set the mono mix output for when the STEREO/MONO

button is used to set the output to mono. The setting state is

shown to the left of the level meters.

1. Press the MENU button to open the

screen.

2. Open the SYSTEM menu.

3. Select

MONO MIX

4. Press the DATA dial to move the cursor right to select the

setting.

5. Turn the DATA dial to set the mono mix.

–6dB L+R

The left and right channels of the stereo

audio track are each attenuated by –6 dB,

summed and then output.

–3dB L+R

The left and right channels of the stereo

audio track are each attenuated by –3 dB,

summed and then output.

L Mono

The left channel of the stereo audio track is

output from both L and R outputs.

R Mono

The right channel of the stereo audio track

is output from both L and R outputs.

OFF

(default

value)

The mono mix function is OFF.

6. After completing the setting, press the HOME button to

return to the Home Screen.

NOTE

The mono mix setting is retained even when the power is turned

OFF.

Master clock and digital output combinations

Depending on the combination of the master clock setting and the playback file sampling frequency, the digital output sampling

frequency varies. This table shows the combinations.

Master

clock

Master clock

setting

Playback file

sampling frequency

SRC

(automatic)

Digital output

sampling frequency

Notes

Internal

INT

44.1 kHz OFF 44.1 kHz The whole system uses 44.1kHz internal clock

44.1kHz FIX

44.1 kHz OFF 44.1 kHz Digital output is always 44.1 kHz

44.1kHz FIX

48 kHz ON 44.1 kHz Digital output is always 44.1 kHz

INT

48 kHz OFF 48 kHz The whole system uses 48kHz internal clock

External

(44.1kHz)

EXT

44.1 kHz OFF 44.1 kHz The whole system uses 44.1kHz external clock

External

(48kHz)

EXT

44.1 kHz ON 48 kHz

While syncing to 48kHz external clock, the

system uses 44.1kHz internal clock

EXT

48 kHz OFF 48 kHz The whole system uses 48kHz external clock

NOTE

The sampling rate converter (SRC) function is turned ON and OFF automatically.

•

If the clock is interrupted when synchronized with a 48kHz external clock, the unit will switch to internal clock, the sampling rate

•

converter (SRC) function will turn ON and output will continue at 48 kHz.
