HS-P82
10 TASCAM HS-P82
New pop-up messages added in HS-P82 V1.10
Message Details and responses Remarks
Cannot Change Now
Fixed in current Fs.
The current sampling frequency cannot be changed.
CF1 Media Full.
CF1:Stopped.
CF2:still RECORDING.
Because CF1 does not have enough space, recording to it has
stopped. Recording to CF2 is continuing.
This occurs when the REC Mode is
set to Mirror.
CF1 Record Error.
CF1:Stopped.
CF2:still RECORDING.
Because an error occurred when recording to CF1, recording to it
has stopped. Recording to CF2 is continuing.
This occurs when the REC Mode is
set to Mirror.
CF2 Media Full.
CF1:still RECORDING.
CF2:Stopped.
Because CF2 does not have enough space, recording to it has
stopped. Recording to CF1 is continuing.
This occurs when the REC Mode is
set to Mirror.
CF2 Record Error.
CF1:still RECORDING.
CF2:Stopped.
Because an error occurred when recording to CF2, recording to it
has stopped. Recording to CF1 is continuing.
This occurs when the REC Mode is
set to Mirror.
Initializing ... The card is being initialized.
Mirror REC is not available.
(CFn is not available)
Since the media cannot be used, mirror recording is disabled.
This occurs when the REC Mode is
set to Mirror.
n = 1 or 2
Mirror REC is not available.
CFn formatting not optimal
for Recording.
Because the media was not formatted by this unit, recording
properly cannot be guaranteed, so mirror recording is disabled.
Format the media with this unit to use it.
This occurs when the REC Mode is
set to Mirror.
n = 1 or 2
Mirror REC is not available.
CFn not recommended type
for Recording.
(not UltraDMA)
Because this card does not meet the required system specifications,
recording properly cannot be guaranteed, so mirror recording is
disabled.
This occurs when the REC Mode is
set to Mirror.
n = 1 or 2
The wordings of the following pop-up messages have changed.
Old message New message Details and responses Remarks
CFn not recommended format
for Recording/Playing.
CFn formatting not optimal
for Recording/Search.
Because the media was not formatted by
this unit, recording/searching properly
cannot be guaranteed, so mirror recording
is disabled. Format the media with this unit
to use it.
n = 1 or 2
This occurs when the card is
formatted with a cluster size
that is smaller than specified
by this unit.
CFn not recommended
for Recording/Playing.
（not UltraDMA）
CFn not recommended type
for Recording/Search.
（not UltraDMA）
Because this card does not meet the
required system specifications, recording/
searching properly cannot be guaranteed.
n = 1 or 2
