HS-P82
2
Home screen
Each number is shown on the project ª
selection screen, folder selection screen
and take selection screen
The numbers are shown on the icons displayed in the list
on each selection screen.
Project selection screen
Folder selection screen
Take selection screen
Addition of a date input button
A Date button has been added to screens where project
names, for example, are edited. This new function allows
the date set in the internal clock to be inserted into the
name.
The following screens have had a Date input button added.
Project name editing screen when creating a new project
•
1st folder name editing screen when creating a new
•
project
Folder name editing screen when creating a new folder
•
Project name editing screen when editing a project
•
name
User word editing screen when editing the next take
•
name
1. To use this button, open the screen where you
can edit the project name, for example, as shown
below.
Project name editing screen
2. Press the Date button to replace the name with
the date set in the internal clock in the yyyy-mm-
dd format.
Project name editing screen
NOTE
If the same project name or folder name already exists,
•
an “_” (underscore) followed by an unassigned number
is added.
After pressing the “Date” button and replacing the name
•
with the date, you can further edit the name on this
screen. (The name of an already created folder cannot be
edited later.)
Next Take Name editing function
added
A NEXT TAKE NAME button has been added to the Home
Screen. Press this button to open a NEXT TAKE NAME
pop-up window where you can edit the name given to
takes. This change will be applied to the next recorded
take.
Take name first half ª
The first half of the take name can be set to either
UserWord or FolderName.
NOTE
The first half of the take name can only be edited when the
unit is stopped.
