TASCAM HS-P82 7
HS-P82
New functions in firmware V1.10
Mirror recording function added
A mirror recording function has been added that allows you to record
simultaneously to 2 CF cards.
In order to make the mirror recording setting easy to see on the
screen, indicators have been added to the CF card remaining time
display button on the Home Screen. These indicators show the status
of both CF cards: recording possible, recording not possible, or not
ready for recording.
Home Screen during playback
Indicator meaning
ª
Recording possible Recording not possible
Not ready for recording
Examples of CF card remaining recording time button
ª
indicators
1 When set to Single
When recording
When not recording When recording not
possible
1
2 When set to Mirror
When recording When not recording
3 When set to Mirror/Mirror disabled
2
When recording When not recording When recording not
possible
1
Mirror recording settings
A REC MODE page has been added to the REC SETUP screen. This
page has a REC Mode item that has Single and Mirror buttons.
Single: Recording can only be made to the currently selected
CF card (default setting).
Mirror: 2 CF cards can be recorded to simultaneously.
NOTE
If the sampling frequency of the current project is 88.2, 96, 176.4 or
192 kHz, the REC Mode setting is always set to Single and cannot
be changed.
Setting button display
ª
1 When set to Single
2 When set to Mirror
3 When set to Mirror/Mirror disabled
1) Conditions that make recording not possible
Current CF card has no remaining capacity
•
Current CF card not loaded
•
Current CF card is not supported (PIO mode)
•
Current CF card format is not supported (not FAT16 or
•
FAT32)
If a take with the same name as set on the
•
NEXT TAKE
NAME page and numbered 999 exists on either of the CF
cards (“---” appears in the take number area on the Home
Screen, NEXT TAKE NAME page)
The total number of entries (files and folders) in the
•
current folders of both CF cards exceed the system limits
(CF card remaining time display button shows “Rec
Limit”)
2) Conditions that disable mirror recording
Non-current CF card has no remaining capacity (recording
•
not possible if the current CF card has no open space
1
)
Non-current CF card is not loaded (recording not possible
•
if the current CF card is not loaded
1
)
Non-current CF card is not supported (PIO mode)
•
(recording not possible if the current CF card is not
supported
1
)
Non-current CF card format is not supported (not FAT16 or
•
FAT32) (recording not possible if the current CF card is an
unsupported format
1
)
One of the CF cards is not compatible with UDMA
•
One of the CF cards has not been formatted by this unit
•
(not formatted with the cluster size recommended for this
unit)
If any of the above conditions apply, mirror recording will
•
not occur, but recording to the current CF card will occur.
NOTE
When set to
•
Mirror, a project/folder will be created on the
unselected CF card to match the current project/folder on the
current CF card. When you start mirror recording, takes with the
same name will be recorded to the projects/folders of the same
name on both CF cards.
If you retake when set to
•
Mirror, only the take on the current
CF card will be erased. The take on the other CF card will not be
erased.
