ProDigit 60

MEASUREMENT FOUNDATION

ProDigit 60

LCD SCREEN ICONS

Up/Down Indicator - The zero line (0°) indicates the level position. The arrow indicates the current angle’s position, either up

or down away from the level (0°).

Battery Power Icon - Indicates the amount of battery power in the unit. Replace batteries when the black power bar disappears.

Sound / Beeper Icon - This icon appears on the screen when the beeper function is activated.

M1-M9 Memory Icon - This icon shows when the memory function is being used. Level can recall the last nine saved measurements.

REF Indicates that the level is working in relative angle mode.

Err Indicates that the level is wrong positioned or wrong operation in calibration.

CAL1 Indicates that the digital level is in calibrating for one direction.

CAL2 Indicates that the digital level is in calibrating for the another direction.

Specications

Recommended use Indoors or Outdoors

Laser class Class2, max laser output ≤1mW

Power supply 2x 1.5V AAA battteries

Angle measuring range 0 to 360°

Optimum operation range 0 to 40°

Accuracy of vials ±0.029°

Accuracy of digital display

±0.05°(level or plumb)

±0.1°(other angles)

Estimated Battery life 10 hours with alkaline batteries
