MEASUREMENT FOUNDATION
ProDigit 60
42
Troubleshooting
Problem Cause Solution
Laser point projection is
weak
Batteries are low voltage. Replace with new batteries
Laser point is not projected •Laser on/off button is not in
ON position.
•Batteries are installed
incorrectly.
•Battery power is low.
•Laser diode is damaged
•Check to make sure the switch
is in On position.
•Re-install batteries with correct
polarity.
•Replace with new batteries
•Take tool to the service center.
The LCD screen can not be
turned on
•Batteries are installed
incorrectly.
•Batteries voltage is low
•The LCD screen is damaged
•Re-install batteries with correct
polarity
•Replace with new batteries.
•Take tool to the service center.
dot line displayed on screen
instead of angle, slope or
pitch
Th e d i gi t al le v el is be ve l
positioned with the working
surface.
Make sure the digital level is
positioned plumb to the working
surface.
Err occurs on LCD during
calibration
•The gradient of the working
surface for calibration exceeds
5 degree
•The di git al leve l i s bevel
positioned with the working
surface.
•The digital level is moved
during the calibration
•Make sure the digital level is
positioned on a level surface
w i t h g r a d i e n t le s s t h a n 5
degree.
•Make sure the digital level is
positioned plumb to the working
surface
•Keep the level unmoved during
calibration.
Wrong setting the current
angle to 0.00°
The digital level is not rotate
180° before starting CAL2
during the calibration.
Re-calibrate the digital level with
a right procedure.
