Zanussi ZHT 630 [6/32] Use maintenance

USE - MAINTENANCE

3 - OPERATION

3.1- Controls are located on the right hand side of the front to operate worktop illumination and select the

most suitable working speed for your cooking. To increase the area of extraction, the glass visor should

be pulled open. The top speed should be used when frying or cooking foods with strong odours, while a

lower speed can be used for normal cooking. To obtain the best performance from your hood, turn it on

before you start cooking and leave it running for a few minutes after your cooking is over to clear the air.

3.2- Pay attention to safety regulations 1.7 and 1.8.

4 - MAINTENANCE AND CLEANING

Regular maintenance and cleaning will ensure good performance and reliability, while extending the

working-life of the hood. Special attention should be reserved to the grease filter and to the charcoal fil-

ter (recycling mode).

4.1 - Grease filter

This retains the solid grease particles and can be supplied in different types. lt is fitted onto the reverse

side of the metal grille panel. Maintenance of the grease filter varies according to the used type.

a-Whatever type of filters used, the filter is easily removed from the grille by pushing the metal wire clips

to one side and removing.

b-Thin synthetic filter (1 mm thick). It should not be washed and should be replaced every two months. If

the filter is provided with a saturation indicator, replace when:

b.1-The violet colour of the dots, which are visible through the metal grille, is spread over the whole

surface of the filter.

b.2-The red colour of the stripes, which is not visible through the metal grille when the filter is clean,

becomes visible from the outside of the metal grille.

c-Multi-layer metal filter. It should be washed once a month in hot water using mild detergent or liquid

soap. It can be washed in a dish-washer. It should not be bent and should be left to drain dry.

WARNING: An excess of grease in the filter not only would affect the performance of the hood, but it is

also a possible fire risk. We strongly recommend therefore to clean and replace filters in accordance

with the manufacturer instructions.

4.2 - Cleaning Metal self- supporting Grease Filters

• The filters are washable and must be cleaned at least every 2 months of operation, or more

frequently for particularly heavy usage.

• Remove the filters one at a time by pushing them towards the back of the group and pulling down at

the same time.

• Wash the filters, taking care not to bend them. Allow them to dry before refitting.

• When refitting the filters, make sure that the handle is visible on the outside.

4.3 - Charcoal filter

The charcoal filter is a chemical filter to be used only when the hood is in the recycling position. To re-

place the charcoal filter, open the grille and remove the thumb screw through the centre of the charcoal

filter. If the filter is of the interlocking type, turn the filter anticlockwise. Replace by reversing the opera-

tion. For a good performance replace the charcoal filter on average every three months.

4.4 - Worktop illumination

If a lamp fails to function at any time, open the metal grille panel and check that the lamp is fully

screwed into the holder. When changing the lamp, an identical replacement must be fitted to ensure a

safe working of the hood.

4.5 - Cleaning

The metal work should be cleaned regularly, at least once a month, using mild household cleaner and

polish. Never use abrasives. For all operations from point 4.1 to point 4.4 and in particular for point 4.3,

pay special attention to the safety regulation 1.9.

Zanussi ZHT 630 [6/32] Use maintenance
