10
3. Oscillation speed adjustmant dial
4. Fixing screw with washer
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Various working tips - 2 pcs
2. Sanding paper - 5 pcs
3. Hexagonal key - 1 pce
PREPARATION FOR OPERATION
SELECTION OF WORKING TOOL
Below table presents examples of use for various working tools.
Name Type of
material
Intended use Example
HCS blade
for wood
Wood,
wood-based
materials,
plastics
Dividing and
plunge cutting
in corners and
hardly accessible
places, near
surface
Cut outs in
furniture
boards, cutting
cove bases
short, plunge
cutting for
fitting floor
panels.
Delta
sanding pad
Wood,
wood-based
materials,
abrasive
materials
Sanding in hardly
accessible places
and in corners on
a hard ground
Removal of
mortar and
glue for ceramic
tiles, sanding
solid wood,
polishing.
INSTALLATION AND REPLACEMENT OF SANDING PAPER
Sanding pad is equipped with hook-and-loop attachment system for
quick and easy replacement of sanding paper. Choose sanding paper
with appropriate gradation depending on the processed material and
desired level of material removal. All types of sanding paper, abrasive
cloths and polishing felt are allowed.
Use only appropriate sanding paper with holes (perforated).
• Put the sanding paper close to the sanding pad (1).
• Place the sanding paper so its holes (a) match with the holes on
the sanding pad (1).
• Press the sanding paper against the sanding pad (1).
• Make sure that the holes on the sanding paper and sanding pad
fully match; it ensures optimal conditions for dust extraction.
• To remove sanding paper, lift edge of it on one side and pull (g. A).
INSTALLATION OF WORKING TOOLS
• Remove working tool if already installed.
• Use hexagonal key to unscrew the fixing screw (4), remove washer
and remove the working tool.
• Place working tool in the tool holder, make sure to close latch joint
of the tool and tool holder.
• You can place working tools onto the tool holder in any latching
position (g. B) to allow for operation most comfortable and safe
for the user.
• Working tool should be installed with bend pointing down.
• Place washer and tighten the screw (4) to install working tool.
Check that the tool is installed properly. Improperly or
inaccurately installed working tools can slip during operation
and cause risk for the user.
DUST EXTRACTION
Dust of some materials may be hazardous to health, like paint
coatings with lead additives, some types of wood e.g. oak or
beech or materials with asbestos. Therefore, we recommend use
of external dust extraction systems, good workplace ventilation
and use of dust-mask with particle lter.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the label of the
tool.
Switching on – slide the switch (2) forward to position I (g. C).
Switching o – slide the switch (2) backward to position O.
Do not cover holes for motor ventilation in the tool body.
SPEED ADJUSTMENT
The rotational speed of the motor is adjusted by turning and setting
the oscillation speed adjustment
dial (3) in a required position. This allows adjustment of working
speed according to properties of your
workpiece. The oscillation speed adjustment ranges from 1 to 6.
The higher the value indicated by the oscillation speed adjustment
dial (3), the higher the working speed
of the device is (g. D).
PRINCIPLES OF OPERATION
Oscillation frequency 20 000 rpm at 2.8° angle allows to work precisely
in small areas and corners with the power tool.
SAWING AND CUTTING
Use only undamaged working tools in good technical condition.
When sawing or cutting wood, bre board, wood-based materials
etc. make sure they do not contain foreign objects like nails,
bolts etc before starting the task. Remove foreign objects or use
proper blade for removal. You can make plunge cuts only in soft
materials like wood, gypsum boards and alike.
Cutting ceramic tiles causes faster wear of working tool.
