54 Technical Data CG Drives & Automation 01-6142-01r0
Emotron FLD 2.0 - IP54 version (Model 69-250 and up also available as IP20)
* Available during limited time and as long as allowed by drive temperature.
Table 24 Typical motor power at mains voltage 525, 575 and 690 V.
AC drive main voltage range, for 52: 440 - 525 V and for 69: 500 - 690 V.
Model
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Frame size
IP
class
Rated
current
[A]
Power
@525V
[kW]
Power
@575V
[HP]
Power
@690V
[kW]
FLD52-003-54 3.0 2.5 1.1 - -
B
IP 54
wall
mounted
FLD52-004-54 4.8 4.0 2.2 - -
FLD52-006-54 7. 2 6.0 3 - -
FLD52-008-54 9.0 7.5 4--
FLD52-010-54 11.4 9.5 5.5 - -
FLD52-013-54 15.6 13.0 7. 5 - -
FLD52-018-54 21.6 18.0 11 - -
FLD52-026-54 31 26 15 - -
C
FLD52-031-54 37 31 18.5 - -
FLD52-037-54 44 37 22 - -
FLD52-046-54 55 46 30 - -
FLD52-061-54 73 61 37 - -
D
FLD52-074-54 89 74 45 - -
FLD69-090-54 108 90 55 75 90
F69
FLD69-109-54 131 109 75 100 110
FLD69-146-54 175 146 90 125 132
FLD69-175-54 210 175 110 150 160
FLD69-200-54 240 200 132 200 200
