CG Drives & Automation 01-6142-01r0 Technical Data 59
8.7 Fuses and glands
8.7.1 According to IEC ratings
Use mains fuses of the type gL/gG conforming to IEC 269
or breakers with similar characteristics. Check the
equipment first before installing the glands.
Max. Fuse = maximum fuse value that still protects the AC
drive and upholds warranty.
NOTE: The dimensions of fuse and cable cross-section
are dependent on the application and must be
determined in accordance with local regulations.
NOTE: The dimensions of the power terminals used in the
cabinet drive models 300 to 3K0 can differ depending
on customer specification.
Table 32 Fuses, cable cross-sections and glands
Model
Nominal input
current
[A]
Maximum value
fuse
[A]
Cable glands (clamping range ) *
mains / motor Brake
##-003 2.2 4
M32 opening
M20 + reducer
(6–12 mm(0.24 - 0.47 in))
M25 opening
M20 + reducer
(6–12 mm(0.24 - 0.47 in))
##-004 3.5 4
##-006 5.2 6
##-008 6.9 10
M32 (12–20)/M32 opening
M25+reducer
(10-14 mm(0.39 - 0.55 in))
M25
(10-14 mm(0.39 - 0.55 in))
##-010 8.7 10
##-013 11.3 16
M32 (16–25)/M32 (13–18)
##-018 15.6 20
##-025 22 25 - (12 - 16 mm(0.55 - 0.63 in))
##-026 22 25
M32
(15–21 mm(0.59 - 0.83 in))
M25
##-030 26 35 - (16 - 20 mm (0.63 - 0.79 in))
##-031 26 35
M32
(15–21 mm(0.59 - 0.83 in))
M25
##-036 31 35 - (20 - 24 mm(0.79 - 0.94))
##-037 31 35
M40
(19–28 mm (0.75 - 1.1 in))
M32
##-045 38 50 - (24 - 28 mm(0.94 - 1.1 in))
##-046 38 50
M40
(19–28 mm (0.75 - 1.1 in))
M32
##-058 50 63 - (24 - 28 mm(0.94 - 1.1 in))
##-061 52 63
M50
(27 - 35 mm(1.06 - 1.38 in))
M40
(19–28 mm (0.75 - 1.1 in))
##-072 64 80 - (28 - 32 mm(1.1 - 1.26 in))
##-074 65 80
M50
(27 - 35 mm(1.06 - 1.38 in))
M40
(19–28 mm(0.75 - 1.1 in))
##-088 78 100 - (32 - 36 mm(1.26 - 1.42 in))
##-090 78 100
48: (Ø17-42 mm (0.67 - 1.65 in))
cable flexible leadthrough or M50
opening.
69: (Ø23-55 mm (0.9 - 2.16 in))
Cable flexible leadthrough or M63
opening.
48: (Ø11-32 mm(0.43 - 1.26 in))
Cable flexible leadthrough or M40
opening.
69: (Ø17-42 mm (0.67 - 1.65 in))
Cable flexible leadthrough or M50
opening.
##-105 91 100 - (32 - 36 mm(1.26 - 1.42 in))
##-109 94 100
48: (Ø17-42 mm (0.67 - 1.65 in))
cable flexible leadthrough or M50
opening.
69: (Ø23-55 mm (0.9 - 2.16 in))
Cable flexible leadthrough or M63
opening.
48: (Ø11-32 mm(0.43 - 1.26 in))
Cable flexible leadthrough or M40
opening.
69: (Ø17-42 mm (0.67 - 1.65 in))
Cable flexible leadthrough or M50
opening.
##-142 126 160 - (40 - 44 mm (1.57 - 1.73 in)) - (36 - 40 mm(1.42 - 1.57 in))
