221
galletti.com VM66000387-C
Air chillers and heat pumps - LER
LER 40 - 420 kW
LER 42 - 92
Dimensional drawings
LEGEND
1 Air outlet, refrigerant side (Ø 28)
2 Air intake, refrigerant side (Ø 22)
3 User circuit inlet (Victaulic 2” ½ )
4 User circuit outlet (Victaulic 2” ½ )
5 User interface
6 Power supply input
7 Optional heat recovery water outlet (1”)
8 Optional heat recovery water inlet (1”)
120
(60)
140 482 150
187 369 193 369
1220 250
1594
1136
80
34
772 1174
171
171
4 - USCITA CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
3 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
2 - ASPIRAZIONE LATO REFRIGERANTE (22)
1 - MANDATA LATO REFRIGERANTE (28)
1
2
3
4
5
5 - INTERFACCIA UTENTE
6 - INGRESSO ALIMENTAZIONE ELETTRICA
7
8
6
1 m
1 m
0,5 m
120
(60)
140 482 150
187 369 193 369
1220 250
1594
1136
80
34
772 1174
171
171
4 - USCITA CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
3 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
2 - ASPIRAZIONE LATO REFRIGERANTE (22)
1 - MANDATA LATO REFRIGERANTE (28)
1
2
3
4
5
5 - INTERFACCIA UTENTE
6 - INGRESSO ALIMENTAZIONE ELETTRICA
7
8
6
1 m
1 m
0,5 m
Model Version
LER 42 S-L
LER 52 S-L
LER 62 S-L
LER 72 S-L
LER 82 S-L
LER 92 S-L
