Galletti LER CS/CL 82 [8/9] Air chillers and heat pumps ler
![Galletti LER CS/CL 82 [8/9] Air chillers and heat pumps ler](/views2/1576153/page8/bg8.png)
225
galletti.com VM66000387-C
Air chillers and heat pumps - LER
LER 40 - 420 kW
Dimensional drawings
LER 144 - 214
LEGEND
1 Fastening points
2 Air outlet, refrigerant side (Ø 42)
3 Liquid return (Ø 35)
4 User circuit inlet (Victaulic 2” ½ )
5 User circuit outlet (Victaulic 2” ½ )
6 User interface
7 Power supply input
8 Optional heat recovery water outlet (1”) - circ. 1
9 Optional heat recovery water inlet (1”) - circ. 1
10 Optional heat recovery water outlet (1”) - circ. 2
11 Optional heat recovery water inlet (1”) - circ. 2
877 2374
(50)
1854
30 817 30
248 369
877
200
1 - PUNTI DI SOLLEVAMENTO
1
2
3
4
5
6
7
987 987 200
1 m
1 m
0,5 m
2374
78
193250
100
250
193
369
91160
7 - INGRESSO ALIMENTAZIONE ELETTRICA
6 - INTERFACCIA UTENTE
2 - MANDATA LATO REFRIGERANTE (Ø42)
3 - RITORNO LIQUIDO (Ø35)
4 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
5 - USCITA CIRCUITO UTILIZZATORE VICTAULIC 2 1/2"}
10
11
8
9
877 2374
(50)
1854
30 817 30
248 369
877
200
1 - PUNTI DI SOLLEVAMENTO
1
2
3
4
5
6
7
987 987
200
1 m
1 m
0,5 m
2374
78
193250
100
250
193
369
91160
7 - INGRESSO ALIMENTAZIONE ELETTRICA
6 - INTERFACCIA UTENTE
2 - MANDATA LATO REFRIGERANTE (Ø42)
3 - RITORNO LIQUIDO (Ø35)
4 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
5 - USCITA CIRCUITO UTILIZZATORE VICTAULIC 2 1/2"}
10
11
8
9
Model Version
LER 144 S-L
LER 164 S-L
LER 184 S-L
LER 204 S-L
LER 214 S-L
