226
galletti.com VM66000387-C
Motor-driven evaporating units LER
Dimensional drawings
LER 244 - 424
1
877
2374
2
3
4
5
6
7
0,5 m 1 m
1 m
1 - PUNTI DI SOLLEVAMENTO
3 - MANDATA REFRIGERANTE (Ø42)
4 - RITORNO LIQUIDO (Ø35)
5 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 3")
6 - USCITA CIRCUITO UTILIZZATORE (VICTAULIC 3")
2 - INTERFACCIA UTENTE
7 - INGRESSO ALIMENTAZIONE ELETTRICA
35
1854
30
200
817 30
276 568
80
1082 250
100
250
200 987 987 200
(60)
95210
1088 568
10
11
8
9
1
877
2374
2
3
4
5
6
7
0,5 m 1 m
1 m
1 - PUNTI DI SOLLEVAMENTO
3 - MANDATA REFRIGERANTE (Ø42)
4 - RITORNO LIQUIDO (Ø35)
5 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 3")
6 - USCITA CIRCUITO UTILIZZATORE (VICTAULIC 3")
2 - INTERFACCIA UTENTE
7 - INGRESSO ALIMENTAZIONE ELETTRICA
35
1854
30
200
817 30
276 568
80
1082 250
100
250
200 987 987 200
(60)
95210
1088 568
10
11
8
9
LEGEND
1 Fastening points
2 Air outlet, refrigerant side (Ø 42)
3 Liquid return (Ø 35)
4 User circuit inlet (Victaulic 3”)
5 User circuit outlet (Victaulic 3”)
6 User interface
7 Power supply input
8 Optional heat recovery water outlet (1”) - circ. 1
9 Optional heat recovery water inlet (1”) - circ. 1
10 Optional heat recovery water outlet (1”) - circ. 2
11 Optional heat recovery water inlet (1”) - circ. 2
Model Version
LER 244 S-L
LER 284 S-L
LER 314 S-L
LER 344 S-L
LER 374 S-L
LER 424 S-L
