Motor-driven evaporating units LER
Dimensional drawings
LER 111 - 181
LEGEND
1 User interface
2 Air outlet, refrigerant side (Ø 28)
3 Liquid return (Ø 22)
4 User circuit inlet (Victaulic 2” ½ )
5 User circuit outlet (Victaulic 2” ½ )
6 Power supply input
7 Optional heat recovery water outlet (1”) - circ. 2
8 Optional heat recovery water inlet (1”) - circ. 2
9 Optional heat recovery water outlet (1”) - circ. 1
10 Optional heat recovery water inlet (1”) - circ. 1
772 1644
150
1606
1594
(60)
482140
34
189 369
171
191 369 476
91160
79
120155
1220 250
1
5
4
3
2
6 - INGRESSO ALIMENTAZIONE ELETTRICA
1 - INTERFACCIA UTENTE
5 - USCITA CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
4 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
3 - RITORNO LIQUIDO (Ø22)
2 - MANDATA LATO REFRIGERANTE (Ø28)
6
0,5 m 1 m
1 m
7
9
10
8
772 1644
150
1606
1594
(60)
482140
34
189 369
171
191 369 476
91160
79
120155
1220 250
1
5
4
3
2
6 - INGRESSO ALIMENTAZIONE ELETTRICA
1 - INTERFACCIA UTENTE
5 - USCITA CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
4 - INGRESSO CIRCUITO UTILIZZATORE (VICTAULIC 2 1/2")
3 - RITORNO LIQUIDO (Ø22)
2 - MANDATA LATO REFRIGERANTE (Ø28)
6
0,5 m 1 m
1 m
7
9
10
8
Model Version
LER 111 S-L
LER 131 S-L
LER 141 S-L
LER 161 S-L
LER 181 S-L
