Page28of56

RG66006951‐Rev.01



2.2 Noise emission

TableV:soundemissionsforLEW‐Lwmodels:Soundpower‐Lp:Soundpressure



Sizes: 040 050 060 070 080 090 110 130 140 160 180 200 210 240 280 310 340 370 420 484

Lw

[db(A)]

Standard

Version

72 72 73 73 74 76 76 77 80 80 81 81 81 82 82 82 83 83 83 86

Low‐Noise

Version

68 68 69 69 70 72 72 73 76 76 77 77 77 78 78 78 79 79 79 82

Lp

[db(A)]

@10m

Standard

Version

44 44 45 45 46 48 48 49 52 52 53 53 53 54 54 54 55 55 55 58

Low‐Noise

Version

40 40 41 41 42 44 44 45 48 48 49 49 49 50 50 50 51 51 51 54

Lp

[db(A)]

@5m

Standard

Version

50 50 51 51 52 54 54 55 58 58 59 59 59 60 60 60 61 61 61 64

Low‐Noise

Version

46 46 47 47 48 50 50 51 54 54 55 55 55 56 56 56 57 57 57 60



2.3 Overall dimensions and weight of the main units

TheLEWproductrangeconsistsofdifferentframes.TheoveralldrawingsoftheLEWmodelsarereportedinthe

followingparagraph.Theycanbereferredtobyconsultingtheidentificationcodesreportedinthetablesinthis

paragraph.Thetablesbelowreporttheweights,referencedrawingsandoveralldimensionsofallth

eLEWmodels.



TableVI:weightandreferencedrawingsofthemainunitsoftheLEWrangewithreferencetotheirframes



 CS‐Chiller

DSDryCooler

Chiller

HS–HeatPump WS–Hotonly

Frame Model

Weigh

t[kg]

Overall

Drawing

Weig

ht

[kg]

Overall

Drawing

Weig

ht

[kg]

Overall

Drawing

Weigh

t[kg]

Overall

Drawing

F1

LEW041 370 HF64000737 370 HF64000737 415 HF64000737 370 HF64000614

LEW042 360 HF64000737 360 HF64000737 385 HF64000737 360 HF64000614

LEW051 430 HF64000737 430 HF64000737 475 HF64000737 430 HF64000614

LEW052 420 HF64000737 420 HF64000737 445 HF64000737 420 HF64000614

LEW061 440 HF64000737 447 HF64000737 502 HF64000737 447 HF64000614

LEW062 430 HF64000737 437 HF64000737 467 HF64000737 437 HF64000614

LEW071 450 HF64000737 457 HF64000737 512 HF64000737 457 HF64000614

LEW072 440 HF64000737 447 HF64000737 482 HF64000737 447 HF64000614

LEW081 470 HF64000737 485 HF64000737 530 HF64000737 485 HF64000614

LEW082 460 HF64000737 475 HF64000737 510 HF64000737 475 HF64000614

LEW091 510 HF64000737 525 HF64000737 575 HF64000737 525 HF64000614

LEW092 490 HF64000737 505 HF64000737 540 HF64000737 505 HF64000614

F2

LEW111 560 HF64000592 585 HF64000592 645 HF64000592 585 HF64000608

LEW112 550 HF64000592 575 HF64000592 605 HF64000592 575 HF64000608

LEW131 570 HF64000592 595 HF64000592 660 HF64000592 595 HF64000608

LEW132 560 HF64000592 585 HF64000592 625 HF64000592 585 HF64000608

LEW141 630 HF64000592 650 HF64000592 720 HF64000592 650 HF64000608

LEW142 615 HF64000592 635 HF64000592 685 HF64000592 635 HF64000608

LEW161 670 HF64000592 705 HF64000592 775 HF64000592 705 HF64000608

LEW162 650 HF64000592 685 HF64000592 740 HF64000592 685 HF64000608

LEW181 710 HF64000592 750 HF64000592 825 HF64000592 750 HF64000608

LEW182 690 HF64000592 730 HF64000592 780 HF64000592 730 HF64000608

F3

LEW144 720 HF64000581 740 HF64000581 830 HF64000581 740 HF64001344

LEW164 740 HF64000581 775 HF64000581 865 HF64000581 775 HF64001344

LEW184 850 HF64000581 890 HF64000581 985 HF64000581 890 HF64001344

LEW204 870 HF64000581 915 HF64000581 1110 HF64000581 915 HF64001344

LEW214 920 HF64000581 965 HF64000581 1065 HF64000581 965 HF64001344

LEW243 950 HF64000581 1060 HF64000609 1120 HF64000609 1060 HF64000627

LEW244 980 HF64000581 1090 HF64000609 1270 HF64000609 1090 HF64000627

LEW283 1050 HF64000803 1120 HF64000609 1180 HF64000609 1120 HF64000627

LEW284 1090 HF64000803 1260 HF64000609 1340 HF64000609 1260 HF64000627

LEW314 1250 HF64000803 1330 HF64000609 1420 HF64000609 1330 HF64000627

LEW344 1290 HF64000803 1380 HF64000609 1470 HF64000609 1380 HF64000627

LEW374 1330 HF64000803 1440 HF64000609 1540 HF64000609 1440 HF64000627

LEW424 1410 HF64000803 1530 HF64000609 1650 HF64000609 1530 HF64000627

LEW484 1510 HF64000803 1520 HF64000609 1710 HF64000609 1710 HF64000627
