Supplementary system components and encoder system integration
7.2 Sensor Module Cabinet-Mounted SMC10
Manual
Manual, 01/2011, 6SL3097-4AC10-0BP2
197
7.2.7 Technical data
Table 7- 7 Technical data
6SL3055-0AA00-5AAx Unit Value
Electronics power supply
Voltage
Current (without encoder system)
Current (with encoder system)
Power loss
V
DC
A
DC
A
DC
W
24 DC (20.4 – 28.8)
≤ 0.20
≤ 0.35
≤ 10
Specification
Transformation ratio of the resolver (ü)
Excitation voltage on the SMC10 when ü=0.5
Amplitude monitoring threshold (secondary tracks)
of the SMC10
V
rms
V
rms
0.5
4.1
1
Excitation voltage (cannot be parameterized) V
rms
4.1
Excitation frequency (synchronized to the current
controller clock cycle)
kHz 5 to 16
PE/ground connection On housing with M4/1.8 Nm screw
Max. encoder cable length m 130
Weight kg 0.45
Degree of protection IP20 or IPXXB
Table 7- 8 Max. frequency that can be evaluated (speed)
Resolver Max. speed resolver / motor
Number of poles Number of pole pairs 8kHz/125 μsec 4kHz/250 μsec 2kHz/500 μsec
2-pole 1 120,000 rpm 60,000 rpm 30,000 rpm
4-pole 2 60,000 rpm 30,000 rpm 15,000 rpm
6-pole 3 40,000 rpm 20,000 rpm 10,000 rpm
8-pole 4 30,000 rpm 15,000 rpm 7,500 rpm
The ratio between the ohmic resistance R and the inductance L (the primary winding of the
resolver) determines whether the resolver can be evaluated with the SMC10. See the
following diagram:
