Supplementary system components and encoder system integration
7.5 Option modules, braking signal
Manual
230 Manual, 01/2011, 6SL3097-4AC10-0BP2
7.5.2.6 Technical data
Safe Brake Relay
Power supply 20.4 to 28.8 V DC
Recommended nominal value of the power supply 26 V DC
(to equalize and compensate for the voltage drop along the
feeder cable to the 24 V DC solenoid of the motor brake)
Max. permissible current drain of
the motor brake
2 A
Max. current requirements (at 24 V
DC)
0.05 A + the current drain of the motor brake
Max. connectable cross section 2.5 mm
2
Weight, approx. 0.17 kg
